5714-11G SINGLE PLASTIC CASTERS WITHOUT BRAKE

Series：57 SERIES SINGLE PLASTIC CASTERS WITHOUT BRAKE

Types：5714-11G

Description ：

57 series casters main frame and wheel core are made of high strength polyamide material, beautiful, anti-corrosion, anti-rust, rotating parts all use precision ball bearing structure, rotation flexible mute, good bearing performance, ensure the service life of casters, tire surface using super quiet TPE material injection molding, wear-resistant, impact- resistant, bearing large whole mute wear-resistant, light and flexible rotation, good elasticity

consult Download

Description

Technical Data
Wheel diameter	100mm
Width of Tread	31.8mm
Baseboard length	76.6 mm
Floor hole distance (L)	57mm
Floor hole distance (w)	40mm
Mounting hole diameter	8.5mm
Swivel Interference	88mm
Overall height	144mm
Temperature	- 10 / + 40 °C
Standard	EN 12531
Weight	0.6kg
Load capacity	75 kg

Dimensions

Structure & Mounting
