ZOGO 86series 8" 200mm Heavy Duty Caster Wheel with Brake

Series：86 SERIES HEAVY DUTY CASTER WHEEL

Types：8688-11g

Description ：

steel frame main structure, with stronger bearing capacity, universal rotation and wheel shaft adopt precision quiet ball bearing, flexible rotation and quiet effect is good; Double linkage brake structure, good braking effect; The wheel plate has the wheel cover design, dustproof, anti-winding, protects the wheel rotation.

consult Download

Description

Drawing

Technical Data
Wheel diameter	200 mm
Width of Tread	-- mm
Castor Width	66mm
Stem rod Dia.	28mm
Length of stem rod	40 mm
Radius of rotation	155mm
Overall height	235.3 mm
Temperature	- 10 / + 40 °C
Standard	EN 12531
Weight	2.1kg
Load capacity 200 kg
Load capacity(Static) 400 kg
